Microelectronic Circuits: Theory and Applications (7th Edition)

Description

This adapted version of Microelectronic Circuits, is designed for undergraduate postgraduate students of electrical and electronics engineering. In addition to updated content and coverage designed to reflect changes in IC technology, the text also provides the most comprehensive, flexible, accurate, and design-oriented treatment of electronic circuits available today.

Key Features

• A revised study of the BJT and the MOSFET and their application in amplifier design: Two short and completely parallel chapters (4 and 5) introduce each of the two transistor types. A new Chapter 6 follows with a combined treatment of transistor amplifiers, emphasizing the similarities and the important differences of the two devices and their unique areas of application.
• Streamlined representation of frequency response: A new Chapter 9 has been introduced to keep the treatment of frequency response all together
• Improved treatment of such important topics as cascode amplifiers, frequency response, and feedback
• Reorganized and modernized coverage of Digital IC Design
• New topics, including Class D power amplifiers, IC filters and oscillators, and image sensors
• A new “expand-your-perspective” feature that provides relevant historical and application notes
• Two thirds of the more than 1350 end-of-chapter problems are new or revised

Table of Contents

1. Electronics and Semiconductors
2. Operational Amplifi ers
3. Diodes
4. Bipolar Junction Transistors (BJTs)
5. MOS Field-Effect Transistors (MOSFETs)
6. Transistor Amplifiers
7. Building Blocks of Integrated-Circuit Amplifiers
8. Differential and Multistage Amplifiers
9. Frequency Response
10. Feedback
11. Output Stages and Power Amplifiers
12. Operational-Amplifier Circuits
13. Filters and Tuned Amplifiers
14. Signal Generators and Waveform-Shaping Circuits
15. CMOS Digital Logic Circuits
16. Advanced Topics in Digital Integrated-Circuit Design
17. Memory Circuits

Authors Biography

Adel S. Sedra is Dean of the Faculty of Engineering, University of Waterloo, Canada.

Kenneth C. Smith is Professor Emeritus in Electrical and Computer Engineering, University of Toronto, Canada.
